At the end of almost every production line, someone stacks boxes or bags onto pallets, hour after hour. It is heavy, repetitive work and one of the first jobs European manufacturers automate. Palletizing robots stack products in a programmed pattern, wrap-ready and consistent, and keep going through night shifts. For how installation and maintenance add up across robot types, see commercial robot costs.
This guide compares the three main ways to automate palletizing, from cobots to heavy industrial arms and complete Senad systems, and explains what to plan before you buy. It is part of our industrial and field robots guide.
Contents
What does a palletizing robot do?
A palletizing robot picks cartons, bags, crates or bundles from a conveyor and places them on a pallet in a defined stacking pattern. Depalletizing is the reverse. A complete cell includes the robot, a gripper (vacuum, clamp, fork or bag gripper), infeed conveyors, pallet handling and safety guarding or scanners. Pattern software lets operators switch products without reprogramming.
Industrial robot, cobot or complete system?
1Cobot palletizers
For lines up to moderate speeds with cartons of up to around 20 kg, a long-reach cobot such as Fairino FR20 (20 kg, 1,854 mm reach) or SIASUN GCR20-1400 can palletize with a smaller footprint and often lighter guarding. See our cobot guide.
2Industrial palletizing robots
For heavy bags, high throughput or tall stacks, fenced industrial arms with high payloads and long reach are the standard choice.
3Complete palletizing systems
Turnkey cells that include conveyors, grippers, pallet dispensing and controls, delivered as a project.
Palletizing robots compared
| Model | Type | Payload | Reach | Typical use |
|---|---|---|---|---|
| Fairino FR20 | Cobot | 20 kg (max 25) | 1,854 mm | Cartons on slower lines |
| SIASUN SR25A-35/1.80 | Industrial arm | 35 kg | 1,803 mm | Cartons, handling; IP65 wrist |
| SIASUN SR50A-50/2.15 | Industrial arm | 50 kg | About 2,158 mm | Heavier cartons, mid-size stacks |
| SIASUN SR210A-210/3.05-DW | Heavy industrial arm | 210 kg | About 3,050 mm | Multi-carton picks, heavy layers |
| SIASUN SR500A-360/2.83 | Heavy-load arm | 360 kg | 2,833 mm | Layer palletizing, very heavy loads |
| Senad bag palletizing robot | Complete system | 2 to 100 kg per pick | Package up to 500 x 960 x 1000 mm | Bags of feed, cement, chemicals |
Values are manufacturer figures listed on Robots Europa. Actual throughput depends on gripper, pattern, pallet changes and safety configuration.
The models in detail
SIASUN industrial arms

SIASUN is one of China’s largest robot makers. SR25A-35/1.80 carries 35 kg over 1,803 mm with ±0.05 mm repeatability and an IP65 wrist, suiting carton palletizing and handling. SR50A-50/2.15 steps up to 50 kg and about 2.15 m reach.

For heavy multi-carton or layer picks, SR210A-210/3.05-DW handles 210 kg with roughly 3.05 m reach and is listed with IP67 protection, while SR500A-360/2.83 carries up to 360 kg across a 2,833 mm envelope.

Senad palletizing systems
Senad supplies complete systems. Its bag palletizing robot machine handles picks from 2 to 100 kg and packages from 200 x 200 x 200 mm up to 500 x 960 x 1,000 mm, suited to sacks of feed, cement, fertiliser or chemicals. The robotic palletizer system stacks cartons in multiple layers and outputs finished pallets, and a combined depalletizing and palletizing system handles both directions.
Robotic palletizer cost: robot arm vs complete cell
The most common budgeting mistake is comparing the price of a bare robot arm with a quote for a working palletizer. The arm is often less than half of the project. A working cell also needs a gripper, infeed, pallet positions, safety equipment, software, integration and CE documentation.
As a reference point, Robots Europa lists the Fairino FR20 cobot (20 kg payload) at about €13,115 and the Fairino FR30 (30 kg payload) at about €14,468. Industrial palletizing arms such as SIASUN SR50A or SR210A and complete systems from Senad and SIASUN are sold on quotation only.
| Quote line | Cobot palletizer | Industrial robotic palletizer | What to check |
|---|---|---|---|
| Robot arm | Cobot, roughly 20 to 30 kg payload | Industrial arm, 50 to 500 kg payload | Payload must include the gripper weight |
| Gripper (end effector) | Vacuum or simple fork gripper | Bag, clamp or layer gripper | Does one gripper cover every SKU? |
| Lift column or base | Often needed for full-height pallets | Usually part of the robot reach | Maximum stack height at your pallet type |
| Infeed conveyor | Short roller or belt conveyor | Conveyor with accumulation and turning | Peak cases or bags per minute |
| Pallet stations | Usually one or two manual positions | Pallet dispenser, slip sheet and outfeed | Can the line keep running during a pallet change? |
| Safety | Area scanners, sometimes no fence | Full fencing, light curtains, interlocked doors | Risk assessment under the Machinery Directive |
| Software and patterns | Pattern wizard included or licensed | Integrator programming | Can your staff add a new pattern themselves? |
| Integration and commissioning | Shorter, sometimes plug and play kits | Longer project with an integrator | Days on site, factory acceptance test |
| CE marking and documentation | Needed for the complete cell | Needed for the complete cell | Who signs the declaration of conformity? |
| Training and service | Operator training, remote support | Operator and maintenance training, service contract | Response time and spare parts stock |
Cobot palletizer or industrial robotic palletizer?
A cobot palletizer suits lighter cartons, moderate speeds and lines where people work nearby or space is tight. An industrial robotic palletizer suits heavy bags, high throughput, several lines feeding one robot or very tall stacks. If your peak rate or case weight sits at the edge of a cobot rating, get both options quoted with the same product data.
Ask each supplier for an itemised quote using the lines above. Offers that look cheap often leave out the gripper, safety or CE work, which you then pay for later.
Planning a palletizing cell
1Product data
List every SKU: dimensions, weight, packaging type and how often products change. Bags behave very differently from cartons.
2Throughput
Define cases or bags per minute at peak, not average, plus pallet change time.
3Pallet and pattern
Pallet type, stack height, interlocking patterns and slip sheets all affect reach and gripper design.
4Floor space and flow
Infeed conveyors, pallet in and out, and forklift or AMR access. Autonomous forklifts can collect finished pallets; see our autonomous forklift guide.
Safety and CE in Europe
Industrial palletizing robots normally work behind fences or light curtains, following ISO 10218 for industrial robots. Whoever assembles the complete cell, often an integrator, is responsible for the CE marking and declaration of conformity of the whole installation under the machinery rules. The EU Machinery Regulation applies from 20 January 2027. Ask your supplier who takes on that role.
Delivery, VAT and CE basics are covered in our guide to buying a robot in Europe.
Referral note: When you request a quote from Robots Europa, mentioning Dijipedya and referral code 08AF5658 helps your enquiry be tracked correctly.
Palletizing robot price in the US
Complete palletizers, such as the Senad robot palletizing machine and the SIASUN palletizing workstation, are sold on quote because conveyors, grippers and safety fencing differ for every line. For a cobot palletizer, the arm gives a price floor: on RobotsUSA (19 October 2026) the Fairino FR20 (20 kg payload) lists at USD 14,500 and the FR30 (30 kg) at USD 15,995. The gripper, column, pallet sensors and software are added on top.
Store links are affiliate links; Dijipedya may earn a small commission if you buy, at no extra cost to you.
Frequently asked questions
How much does a robotic palletizer cost?
It depends on what is included. A palletizing cobot arm alone lists around €13,000 to €14,500 (Fairino FR20 and FR30, Robots Europa, October 2026), but a complete cell adds the gripper, conveyor, pallet stations, safety equipment, integration and CE work. Ask for an itemised quote.
What is a cobot palletizer?
A palletizing cell built around a collaborative robot. It is usually smaller and quicker to set up than an industrial palletizer and suits lighter cartons at moderate speeds.
Cobot or industrial robot for palletizing?
Cobots suit lighter cartons and moderate speeds with a small footprint. Heavy bags, high throughput and tall stacks need industrial palletizing robots.
Can a palletizing robot handle bags?
Yes, with a bag gripper. Senad’s bag palletizing system handles picks from 2 to 100 kg.
Who is responsible for CE marking of a palletizing cell?
The party that assembles the complete cell, often the integrator, issues the declaration of conformity for the whole installation.
Can one robot palletize several lines?
Yes, if the lines are close and throughput allows. Pattern software and multiple pallet stations make this possible.
How much does a palletizing robot cost?
Complete palletizing systems are quoted. For cobot palletizers, the arm alone costs about USD 14,500 to 16,000 in the US (Fairino FR20 and FR30), before the gripper, column, safety and software.
Compare industrial and palletizing robots and request a project quote for your line.
Affiliate link: we may earn a commission if you buy through it, at no extra cost to you.
